Steel Street Light Poles
Professional Steel Street Light Poles
Our high-performance lighting poles are engineered from premium Q235/Q345 steel. Featuring hot-dip galvanization (ISO 1461), they provide 20+ years of maintenance-free service in any weather condition.
Get Technical DrawingsTechnical Specifications
Material
High-Quality Q235B / Q345B Steel
Height
3 Meters – 15 Meters (Customizable)
Shape
Conical, Octagonal, Round, or Polygonal
Surface Treatment
Hot-dip Galvanized (ISO 1461)
Welding
Automatic Submerged Arc Welding
Wind Resistance
Engineered for up to 160 KM/H
Technical Specifications of Steel Street Light Poles
| Height (m) | Wall Thickness (mm) | Top Diameter (mm) | Bottom Diameter (mm) | Base Plate Dimensions (mm) | Anchor Bolts (Size & Qty) | Typical Application |
|---|---|---|---|---|---|---|
| 3m | 2.5–3.0 | 60–76 | 120–140 | 250 × 250 × 12 | M16 × 4 pcs | Garden roads, residential pathways, parks, pedestrian areas |
| 4m | 2.5–3.0 | 60–76 | 130–150 | 280 × 280 × 14 | M18 × 4 pcs | Community roads, small parking areas, landscape lighting |
| 5m | 3.0–3.5 | 70–89 | 140–165 | 300 × 300 × 16 | M18 × 4 pcs | Residential streets, local roads, public walkways |
| 6m | 3.0–3.5 | 76–89 | 150–180 | 320 × 320 × 18 | M20 × 4 pcs | Urban streets, commercial areas, parking lots |
| 8m | 3.5–4.0 | 89–100 | 180–220 | 400 × 400 × 20 | M22 × 4 pcs | Main roads, industrial areas, municipal street lighting |
| 10m | 4.0–4.5 | 100–120 | 220–260 | 450 × 450 × 22 | M24 × 4 pcs | Wide roads, highways, large parking lots, logistics zones |
| 12m | 4.5–5.0 | 120–140 | 260–300 | 500 × 500 × 25 | M27 × 4 pcs | Highways, arterial roads, ports, airports, large outdoor areas |
All steel street light poles can be manufactured with hot-dip galvanized surface protection in accordance with project requirements based on ASTM A123 and ISO 1461. The above specifications are general reference ranges for standard roadway lighting projects, and final dimensions should be confirmed according to wind load, pole height, luminaire weight, arm length, foundation design, and local installation conditions. We support custom engineering based on specific wind load requirements, project drawings, anchor bolt layouts, base plate details, and luminaire mounting interfaces. OEM and project-specific designs are available for municipal, commercial, highway, and infrastructure lighting projects.
Base Plate
Heavy-duty base plates are robotically welded to the pole shaft, ensuring high structural strength, accurate alignment, and reliable stability under long-term outdoor loads.
Handhole & Cover
Waterproof handholes with fitted covers provide convenient access for cable connection, inspection, and maintenance while protecting internal wiring from rain, dust, and corrosion.
Arm Brackets
Single-arm and double-arm brackets are available to match different roadway lighting layouts, offering a secure fit for luminaires and stable performance in outdoor conditions.
Anchor Bolts
Hot-dip galvanized J-bolts provide strong foundation anchoring, excellent corrosion resistance, and dependable connection strength for long-term installation safety.
CNC Cutting
High-precision CNC plasma cutting is used for Q235/Q345 steel plates, ensuring accurate dimensions, smooth cutting edges, and consistent material preparation for pole forming.
CNC Cutting
High-precision CNC plasma cutting is used for Q235/Q345 steel plates, ensuring accurate dimensions, smooth cutting edges, and consistent material preparation for pole forming.
Tailored Engineering & Custom Steel Street Light Poles
As a professional B2B street light pole manufacturer, JOYIME understands that every infrastructure project requires precise calculations. We offer comprehensive customization services based on your structural drawings, local wind load ratings, and specific environmental demands. Our in-house engineering team provides expert CAD design and structural analysis to match your project’s exact needs, from urban roadways and coastal highways to high-wind areas.
Advanced Fabrication and Surface Protection Standards
Our street light poles are manufactured using high-grade Q235B / Q345B steel to guarantee high tensile strength. Utilizing advanced automatic submerged arc welding, we achieve 100% penetration and consistent, flawless weld seams. To ensure a service life of over 25 years, every pole undergoes heavy-duty hot-dip galvanization compliant with international standards like ISO 1461 and ASTM A123. This creates a reliable rust-proof barrier, even in harsh coastal or tropical environments.
Full Specification Guide for Customizable Solutions
• Shaft Style: Conical, Octagonal, Round, Polygonal, or Fluted
• Arm Configurations: Single Arm, Double Arms, Triple Arms, or Custom Bracketry
• Height Range: 3 Meters to 15 Meters (Tailored to your specific site needs)
• Coating Options: Hot-dip Galvanized only, or Duplex System (Galvanized + Electrostatic Powder Coated in RAL colors)
• Accessories Available: Anchor Bolts, Ground Cages, Service Doors, and Decorative Base Covers
Engineered Steel Street Light Poles for Reliable Outdoor Lighting Projects
JOYIME steel street light poles are designed for long-term outdoor use in municipal roads, highways, industrial parks, commercial areas, residential communities, parking lots, ports, and public infrastructure projects. Compared with ordinary lighting supports, steel street light poles provide stronger structural performance, better wind resistance, and greater flexibility for customized project requirements.
Each pole can be manufactured according to project drawings, lighting layout plans, installation conditions, and local engineering standards. Whether the project requires single-arm street light poles, double-arm poles, decorative lighting columns, or heavy-duty galvanized poles for coastal environments, JOYIME can provide tailored manufacturing solutions to support different road lighting applications.
Custom Manufacturing Based on Project Drawings
For professional lighting contractors, EPC companies, distributors, and infrastructure developers, standard pole dimensions are often not enough. Different projects may require different pole heights, shaft diameters, wall thicknesses, base plate sizes, outreach arm lengths, bolt patterns, cable holes, service doors, and surface treatments.
JOYIME offers custom steel street light poles based on customer drawings, technical specifications, or sample designs. Our engineering team can assist with CAD design, structural optimization, wind load requirements, and production feasibility analysis before manufacturing. This helps reduce installation risks and ensures that the finished poles match the actual site conditions.
Hot-Dip Galvanized Surface Protection for Long Service Life
Outdoor steel poles are constantly exposed to rain, sunlight, humidity, dust, salt air, and temperature changes. To improve corrosion resistance, JOYIME steel street light poles are normally treated with hot-dip galvanization after fabrication. This process forms a durable zinc coating on both the internal and external surfaces of the steel pole, helping protect the structure from rust and oxidation.
For coastal areas, tropical regions, industrial zones, or high-humidity environments, hot-dip galvanized steel street light poles are a practical and reliable choice. Optional powder coating can also be applied over the galvanized surface to create a duplex protection system. This not only improves corrosion resistance but also provides a more attractive appearance with customized RAL colors.
Strong Structure for Wind Load and Outdoor Safety
A Steel Street Light Poles is not only a support for luminaires. It must also withstand wind pressure, vibration, lighting fixture weight, installation load, and long-term environmental stress. JOYIME pays close attention to shaft forming, welding quality, base plate strength, and anchor bolt connection design.
Depending on project requirements, our steel street light poles can be designed with conical, octagonal, round, polygonal, or fluted shaft profiles. The pole thickness and diameter can be adjusted according to height, wind speed, arm length, and fixture loading. Proper structural design helps improve safety, reduce deformation, and extend the service life of the lighting system.
Suitable for Global Infrastructure and Road Lighting Projects
JOYIME supplies steel street light poles for different types of international projects, including urban road lighting, highway lighting, bridge lighting, parking area lighting, solar street lighting, smart city lighting, and public landscape lighting. Our products can be customized for different markets and installation standards, making them suitable for contractors, wholesalers, lighting companies, and government-related infrastructure projects.
From simple galvanized street light poles to powder-coated decorative poles and project-specific lighting columns, JOYIME focuses on stable quality, flexible customization, and reliable production capacity. We understand that every road lighting project has different requirements, and our goal is to provide steel pole solutions that are practical, durable, and easy to install.
Why Choose JOYIME Steel Street Light Poles
Choosing JOYIME Steel Street Light Poles means working with a manufacturer that understands both production and engineering requirements. We provide support from technical communication to fabrication, surface treatment, inspection, and export packaging. Our factory can manufacture poles according to drawings and project specifications, helping customers save time during procurement and installation preparation.
For your next road lighting, highway lighting, municipal lighting, or infrastructure project, JOYIME steel street light poles offer a dependable solution with customizable design, strong steel structure, corrosion-resistant surface treatment, and long-term outdoor performance.
Get a Customized Quote & Technical Drawings
Submit your specifications or project drawings. Our engineering team will respond with full CAD design files and a competitive price breakdown within 12 hours.
