LED Tunnel Lights 613204
LED Tunnel Lights
a.Independent intellectual design,integrated multiple advanced technologies.
b.Die-cast aluminum for lamp structure,anti-impact and corrosion.
c.High thermal conductivity aluminum for heat radiation.
d.High-strength toughened glass,high light transmittance.
e.Superior heat radiation:follow principles of conduction,convection,and radiation, patented technical thermal layer raises the radiator’s thermal conductivity.LED junction temperature is below 75°C,when environmental temperature is 35°C.
f.Humanized structural design,easy the installation and maintenance.
Description
Applications
Factory ,warehouse ,tunnel ,stadium etc
Features:
a. Independent intellectual design,integrated multiple advanced technologies.
b. Color temperature:6500/4000/3000K.
c.Input voltage(V):AC100-277.
d.Frequency range:50/60Hz.
e.Power factor>0.9.
f.CRI>70.
g.Working temperature:-35 to 50C.
h.LED Lifetime:70,000hours.
i.IP65.
| ORDER NO. | 613204A | 613204B | 613204C | 613204D | 613204E | 613204F |
| LED QTY | 108PCS | 108PCS | 72PCS | 72PCS | 48PCS | 48PCS |
| RATED POWER | 113W | 175W | 89W | 115W | 55W | 73W |
| LUMINOUS FLUX | 13720/12700/10290LM | 20040/18560/15030LM | 10600/9810/7950LM | 13070/12110/9810LM | 6520/6040/4890LM | 8400/7780/6300LM |
| N.W | 12KGS | 12KGS | 9.4KGS | 9.4KGS | 9KGS | 9KGS |
| G.W | 14KGS | 14KGS | 10.9KGS | 10.9KGS | 10.6KGS | 10.6KGS |
| DIMENSION(MM) | 685*375*320 | 685*375*320 | 525*375*320 | 525*375*320 | 525*375*320 | 525*375*320 |
