LED Tunnel Lights 613202
LED Tunnel Lights
a.Lamp shape follows fluid dynamics principles,avoid dust.
b.Module design offers more selections for different applications,helps cooling LEDS and improves the lamp life.
c.Counter flow design for cooling.
d.Unique dust-cover plate.
e.Portable driver pack,easy for installation and maintenance.
f.IP66 for LED modules,ASTM6063 radiating block,black anodic oxidation treatment on surface,micro cooling treatment for heat fins.
Description
Applications
Factory ,warehouse ,tunnel ,stadium etc
Features:
a.Lamp shape follows fluid dynamics principles,avoid dust.
b.Color temperature :6500/4000/3000K.
c.Input voltage(V):AC100-277.
d.Frequency Range:50/60Hz.
e.Power factor>0.9
f.CRI>70.
g.Working temperature:-35 to 50C.
h.LED Lifetime:70,000hours.
i.IP65.
| ORDER NO. | 613202A | 623202B | 613202C |
| LED QTY | 48PCS | 36PCS | 24PCS |
| RATED POWER | 117W | 92W | 60W |
| LUMINOUS FLUX | 12410/11490/9310LM | 9510/8800/7310LM | 12410/11490/9310LM |
| N.W | 6.6KGS | 5.8KGS | 5.4KGS |
| G.W | 7.4KGS | 6.6KGS | 6.2KGS |
| DIMENSION(MM) | 500*430*165 | 430*430*165 | 430*430*165 |
