LED Tunnel lights 613101
COB LED Tunnel lights
a.Electrostatic spraying and aluminum oxidation surface
b.Bridgelux COB LED
c.High reliability Meanwell driver.
d.Dialux simulation service provided.
e.With CE and Rohs
Description
Features：
a.Original raw aluminum material to make the casings. Extruded aluminum heat sinker for the main body. With high-strength tempered glass, and also high pure alloy reflector cover. Which make the lamp heavy and not easy to break.
b.Using buckles or screws differently as an alternative..
c.IP65
d.Epistar / Bridgelux LED chip.
e.3 year warranty for normal.
f.Input Wattage: 90-277V AC.
g.CCT 5000-5650K.
h.Ra >=70
Applications of the occasion:
For tunneling and outdoor lighting, such as architecture ,industrial area, factory, gym, garden, sea port and so on.
| Order No. | Lumens | LED QTY | Lamp Power | Dimension | Net Weight | Gross Weight | Carton Dimension |
| 613101-W80 | 6400 /- 500 LM | 80W x 1 | 90 /- 4 W | 292x367x224 mm | 9.5 Kg | 10 Kg | 440x320x380 mm |
| 613101-W160 | 15000 /- 500 LM | 80W x 2 | 170 /- 6 W | 292x610x224 mm | 14.8 kg | 15.5 kg | 670x310x370 mm |
| 613101-W200 | 18000 /- 500 LM | 100W x 2 | 220 /- 10 W | 292x690x224 mm | 17.8 kg | 18.5 kg | 760x380x320 mm |
| 613101-W240 | 22500 /- 500 LM | 80W x 3 | 260 /- 10 W | 292x975x224 mm | 26.2 kg | 30.8 kg | 420x1080x330 mm |
| 613101-W360 | 32500 /- 600 LM | 90W x 4 | 380 /- 10 W | 292x1250x224 mm | 36.1 kg | 39.7 kg | 420x1340x330 mm |
| 613101-W400 | 35500 /- 700 LM | 100W x 4 | 420 /- 15 W | 292x1360x224 mm | 39.2 kg | 43 kg | 420x1410x330 mm |
