LED Street Lights 528202
COB Led Street Lights
a. Unique design for heat dissipation and heat conduction, making the lamp lighter and better for heat dissipation.
b. using COB Bridgelux led chip
c. High quality Mean well supply
d. Dialux simulation service provided
Description
Application:
Street, Garden ,Squares ,School ,Park ,Yards ,pavements
Features:
1 Unique design for heat dissipation and heat conduction ,making the lamp lighter and better for heat dissipation.
2 Beauty for the appearance ,using COB Bridgelux led chip.
3 IP65.
4.System rating is at 50,000 hours
5.CE PSE ROHS.
6.Temperature Rated at – 40 to 40 C.
7.Standard colors: Silver .RAL or custom colors available with minimum order quantities and extended lead times.
8.Color temperature 3000K 4000K 5000K 6000K optional.
9.Driver efficiency >0.9
10.Input Voltage: 100-277V AC
11.Storage temperature: -35 to 35C
| Order No. | LED | CCT | CRI | Luminous Flux | Dimension (mm) | System Power |
| 528202-W10 | Bridgelux 45 | 6000K /- 510K | >=70 | 950 LM | 444*186*120 | 12W /- 3W |
| 528202-W20 | Bridgelux 45 | 6000K /- 510K | >=70 | 1780 LM | 444*186*120 | 23W /- 3W |
| 528202-W30 | Bridgelux 45 | 6000K /- 510K | >=70 | 2980 LM | 444*186*120 | 33W /- 3W |
| 528202-W40 | Bridgelux 45 | 6000K /- 510K | >=70 | 3980 LM | 444*186*120 | 44W /- 5W |
| 528202-W50 | Bridgelux 45 | 6000K /- 510K | >=70 | 4800 LM | 650*240*120 | 55W /- 5W |
| 528202-W60 | Bridgelux 45 | 6000K /- 510K | >=70 | 6300 LM | 650*240*120 | 66W /- 5W |
| 528202-W70 | Bridgelux 45 | 6000K /- 510K | >=70 | 7000 LM | 650*240*120 | 76W /- 5W |
| 528202-W80 | Bridgelux 45 | 6000K /- 510K | >=70 | 7800 LM | 650*240*120 | 88W /- 5W |
