LED Flood Lights 527214
LED Flood Lights
a.Owned design patent,have various advanced technologies.
b.Used the die-casting aluminum for the main part,which has advantages for anti-shock and anti-corrosion.
c.The main material for radiator id 6063 aluminum alloy,made by special treatment .
d. With high performance for light distribution.
e.High strength toughened glass,using special treatment with better ultraviolet resistance.
f.Humanized structural design,convenient for installation and maintenance:
1.Installstion angle could be adjusted between -45 to 75 degree,which is suitable to various installation methods.
2.External box for wire,patent design,makes wire connection outside of the wiring space.Convenient to operate and enhance the light IP.
Description
Applications of the occasion.
For outdoor lighting, such as architecture ,industrial area, factory, gym, garden, sea port and so on.
Features:
a.Color:Single/RGB.
b.The power factor is greater than 0.9.
c.Input voltage(V):AC100-277.
d.Frequency range:50/60Hz.
e.CRI>70.
f.Beam angle:10° 25° 40° 60°
g.Working temperature:-35 to 50C.
g.LED Lifetime:70,000hours.
h.IP65.
ORDER NO. | 527212A | 527212B | 527212C | 527212D | 527212E | 527212F | 527212G | 527212H |
LED QTY | 132PCS | 132PCS | 72PCS | 72PCS | 48PCS | 48PCS | 36PCS | 36PCS |
RATED POWER | 158/135W | 198/165W | 86/76W | 127/112W | 58/52W | 76/68W | 45/40W | 66/58W |
LUMINOUS FLUX | 12000/5380LM | 14640/6563LM | 6652/2981LM | 8781/3636LM | 4416/1980LM | 5388/2415LM | 3517/1577LM | 4642/2081LM |
INSTALLATION PIPE DIAMETER | Φ12X100MM | Φ12X100MM | Φ12X100MM | Φ12X100MM | Φ11X100MM | Φ11X100MM | Φ11X100MM | Φ11X100MM |
N.W | 16.40KGS | 16.40KGS | 10.20KGS | 10.20KGS | 7.00KGS | 7.00KGS | 6.70KGS | 6.70KGS |
G.W | 18.40KGS | 18.40KGS | 10.90KGS | 10.90KGS | 7.70KGS | 7.70KGS | 7.10KGS | 7.10KGS |
DIMENSION(MM) | 565*195*640 | 565*195*640 | 445*185*535 | 445*185*535 | 340*150*460 | 340*150*460 | 355*165*475 | 355*165*475 |
