LED Flood Lights 527206
LED Flood Lights
a.The lamp body is using high strength die-casting aluminum,and cover using high strength toughened glass,anti-impact,abrasion resistant.
b.Powerful features,easy to control,with 12 kinds of internal dynamics programs,and original.
c.Logarithmic dimming,mixed lighting technology,which makes lighting soft and gorgeous.Integrated narrow lighting technology,can realize 4.5 degree beam angle.
Description
Applications of the occasion.
For outdoor lighting, such as architecture ,industrial area, factory, gym, garden, sea port and so on.
Features:
a.Color:Single/RGB.
b.Frequency range:50/60Hz.
c.Input Voltage(V):AC100-277.
d.Control mode:CC/DMX512.
e.Beam angle:4.5°
f. Working temperature:-35 to 50C.
g.LED Lifetime:70,000hours.
h.IP66.
| ORDER NO. | 527206A | 527206B |
| LED QTY | 12PCS | 9PCS |
| RATED POWER | 30.8W | 24.2W |
| LUMINOUS FLUX | 2081/1156LM | 1556/864LM |
| INSTALLSTION PIPE DIAMETER | Φ8.5X60MM | Φ8.5X15MM |
| N.W(inner) | 3.55KGS | 3.5KGS |
| N.W(outer) | 31.2KGS | 28KGS |
| G.W(inner) | 3.9KGS | 3.85KGS |
| G.W(outer) | 31.6KGS | 28.4KGS |
| DIMENSION(inner) | 305*275*260MM | 305*275*260MM |
| DIMENSION(outer) | 675*615*585MM | 675*615*585MM |
