LED Flood Lights 527203
LED Flood Lights
a.Super narrow optical design,entire angle reach 4.5degree,single light can lighting distance reach 200 meters.
b.Lamp adopt aluminum alloy,high heat dissipation.Low weight design.
c.Multiple control function,the intelligent logarithmic dimming technology enrich the color saturation.
d.Strong structure function,adjust angle can precision to 2.5 degree:use flexible,can load sighting telescope accurate positioning for the long distance.
Description
Applications of the occasion.
For outdoor lighting, such as architecture ,industrial area, factory, gym, garden, sea port and so on.
Features:
a.Input Voltage(V):AC100-277.
b.Frequency range:50/60Hz.
c.Control mode:CC/DMX512.
d.Beam angle:4.5°
e.Working temperature:-35 to 50C.
f.LED Lifetime:70.000hours.
g.IP66 suitable for wet location.
| ORDER NO | 527203A | 527203B |
| LED QTY | 132PCS | 66PCS |
| RATED POWER | 316W | 158W |
| COLOR(SINGLE) | 36R36G36B24W | 18R18G48B12W |
| LUMINOUS FLUX | 22160/12311LM | 11227/6257LM |
| N.W(inner) | 27KGS | 14.2KGS |
| N.W(outer) | 30KGS | 16.5KGS |
| G.W(inner) | 31KGS | 16.1KGS |
| G.W(outer) | 35KGS | 18.4KGS |
| DIMENSION(single) | 866*777*225MM | 790*450*200MM |
| DIMENSION(RGBW) | 866*777*335MM | 790*450*310MM |
